PTO Watermelon Seed Harvesting Machine Equipment 25HP-45HP
| Place of Origin | HENAN, CHINA |
|---|---|
| Brand Name | CQ |
| Certification | CE, ISO |
| Model Number | CQ-PTG300 |
| Minimum Order Quantity | 1 set |
| Price | $2200-$3000/set |
| Packaging Details | Standard export wooden box |
| Delivery Time | 10-15 work-days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 200 unit/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Pumpkin Seeds Harvester | Row Distance | 5 - 10 Mm |
|---|---|---|---|
| Capacity | 200-500kg/h | Cleaning Rate | ≥90% |
| Efficiency | 3-5km/h | Tractor Power | 25 - 45 HP |
| Voltage | 380V, Three-phase | Working Width | 1500 Mm |
| Warranty | 1 Year | ||
| Highlight | PTO seed harvesting machine,25HP seed harvesting machine,PTO seed harvesting equipment |
||
Product Description
PTO Watermelon Seed Harvesting Machine Equipment 25HP-45HP
Key Specifications
| Attribute | Value |
|---|---|
| Product name | pumpkin seeds harvester |
| Row Distance | 5 - 10 mm |
| Capacity | 200-500kg/h |
| Cleaning rate | ≥90% |
| Efficiency | 3-5km/h |
| Tractor Power | 25 - 45 HP |
| Voltage | 380V, three-phase |
| Working Width | 1500 mm |
| Warranty | 1 year |
Working Principle
- Connects to small tractor via PTO for power transmission
- Fruits are fed into the hopper for processing
- Crusher shaft breaks down watermelon/pumpkin
- Separating drum removes skin and meat from seeds
- Cleaning drum further refines and separates seeds
- Final cleaned seeds are discharged through outlet
Product Overview
The pumpkin and watermelon seeds harvester is a dual-purpose agricultural equipment that performs crushing, squeezing, and seed separation in one continuous operation. Designed for efficient field use, this machine offers:
- High-capacity processing of 200-500kg per hour
- Mobile operation capability for field flexibility
- Simple operation with safe, reliable performance
- Optimized structure for maximum seed extraction
Technical Parameters
| Capacity | 200-500Kg/H |
| Cleaning Rate | ≥90% |
| Breaking Rate | ≤50% |
| Seeds Outlet Height | ≥300mm |
| Voltage | 380V/50HZ |
| Power | 18KW |
| Dimension | 2000*1750*1450mm |
| Weight | 378KG |
Product Gallery
Our Services
• Installation video helping customer assembly
• 24 hours technical support by mobile or email
• One years free warranty period
